Planer-thicknesser SD510 Eco
DETAILS

Electrical vertical
adjustment of the
thicknesser.
Fine adjustment with
handwheel.		   Sturdy columns
The thicknesser is based on
to 4 sturdy columns.		   Cast-iron sections of the
bearing of the in- and
outfeed rollers and planer
shaft.


Exchangeable table lips
ensure an enormous noise
reduction.		   Planer fence
Adjustable planer fence: tilt
between 45° and 90°.		   It is possible to work pieces
of wood with a thickness up
to 250mm.


Spiral infeed rollers
Spiral infeed rollers
guarantee an efficient
through-feed of the wood and
so a good surface.		   Heavy hinges
Heavy hinges and strong
springs for smooth and easy
opening of the table.

OPTIONS

Tersa
Optional the machine can be
equipped with the Tersa
system; to achieve a fast
exchange and perfect
adjustment of the knives.		   Morticer
The morticer is equipped
with steel guidance and 6
linear ball bearings, warranty
for an easy operation of the
machine (and maintenance
free!). The drilling head
rotates with 3000 r/min. For
working with the larger
surfaces e.g. doors, the
control lever can be put into
the lower position.		   2 Friction reduction rolls
Easier sliding of wet wood.

TECHNICAL SPECIFICATIONS
SD510 ECO Technical data
Tension 230 V / 400 V
Weight 900kg (SDB 1000 kg)
Dimensions crate SD510 2300 x 1150 x 980 mm
Dimensions crate SDB510 2300 x 1500 x 980 mm
Planer
Planer width 510 mm
Total length planer tables 2250 mm
Diameter cutter block 100 mm
Knives 4
Dimensions knives 510 x 30 x 3 mm
R.p.m. 6000
Dimensions planer fence 100 x 200 mm
Inclination planer fence 90° - 45°
Max. depth of cut 6 mm
Motor power 5,5 kW (7,5 PS/hp) option 10PS/hp
Thicknesser
Dimensions thicknesser table 855 x 510 mm
Capacity thicknesser 265 mm
Feeding speed 8 - 16 m/min
Diameter feed rollers 50min.
Electrical rise and fall thicknesser table 375 mm/min.
Morticer (option)
Dimensions table 600 x 300 mm
Travel 200 x 150 x 150 mm
Chuck 0 - 16 mm
RPM 3000
Equipment
Electrical rise and fall thicknesser table Standard/standard
Heigth adjustment with hand wheel SD 510 ECO
Mechanical position indicator SD 510 ECO
TERSA planer arbor Option / option
2 friction reduction rolls in thicknesser table Option / option
